Squeeze Momentum with ADX Filter and Multi-Cycle Waves

Title:
Squeeze Momentum with ADX Filter and Multi-Cycle Waves

Description:
This indicator integrates three well-established technical analysis methodologies into a single oscillator to help traders assess volatility compression, trend strength, and cyclical momentum alignment:

Squeeze Momentum (TTM-style) – Based on Bollinger Bands and Keltner Channels, it identifies periods of low volatility ("the squeeze") followed by directional breakouts. The histogram reflects momentum using linear regression relative to a dynamic centerline. Positive values indicate upward momentum; negative values indicate downward momentum.
ADX with DI+/DI- (Welles Wilder, 1978) – The Average Directional Index is dynamically scaled to match the visual range of the Squeeze histogram. A user-defined Key Level (default: 32) serves as a reference threshold: when ADX rises above this level, it suggests a strong trend is present. DI+ (green) and DI- (red) show directional bias.
Multi-Cycle Waves (55/144/233) – Inspired by adaptive cycle analysis and MACD-style oscillators, these smoothed momentum waves help identify confluence across multiple timeframes. They are optional and appear as shaded areas when enabled.
Key Features:

The Squeeze Momentum Line appears as black/gray crosses at the zero level, indicating momentum polarity without visual clutter.
The Key Level is shown as a thick gray horizontal line, representing the ADX threshold in the scaled oscillator space.
ADX is plotted with increased line width (3) for better visibility.
All components are dynamically scaled to share the same vertical axis, enabling direct visual comparison.
Attribution:

Bollinger Bands: John Bollinger
Keltner Channels: Chester Keltner
Squeeze concept popularized by Linda Raschke and John Carter
ADX/DI system: J. Welles Wilder Jr.
Multi-cycle wave logic: inspired by John Ehlers’ work on market cycles
Integration, scaling logic, and visualization: © Carlos Mauricio Vizcarra (2025)
This script is published under the Mozilla Public License v2.0. It is open-source, non-promotional, and designed for educational and analytical use only. No investment advice is provided.
